ARMANO RSCh 63-3 Bourdon Tube Safety Pressure Gauge with Reed Contact R4
Manufacturer: ARMANO Messtechnik GmbH · Xylem Article No. 47151
Stainless-steel Bourdon tube safety pressure gauge with 63 mm case, 316L wetted parts and indirect Reed contact R4. Designed for reliable pressure measurement and switching applications in industrial systems.
- 63 mm (2½") stainless-steel bayonet ring case
- Safety category S3 to DIN EN 837-1
- 316L (1.4404) wetted parts
- Indirect Reed contact, type R — R4
Price
Enquire About Price
Priced on application · freight quoted with order
Talk to an engineer
Send your existing gauge details or a photo of the dial and we will confirm the right replacement for your installation.
Product description
ARMANO RSCh 63-3 Safety Pressure Gauge
The ARMANO RSCh 63-3 is a stainless-steel Bourdon tube safety pressure gauge designed for reliable mechanical pressure measurement. It features a 63 mm (2½") stainless-steel bayonet ring case and complies with safety category S3 according to DIN EN 837-1.
This specific version is equipped with an indirect Reed contact (type R), switching function R4, and a 6 mm process connection for clamping-ring / Swagelok-type fittings.
Technical data
Technical Specifications
| Manufacturer | ARMANO Messtechnik GmbH |
|---|---|
| Model | RSCh 63-3 |
| Nominal size | 63 mm (2½") |
| Instrument type | Bourdon tube safety pressure gauge |
| Safety category | S3 according to DIN EN 837-1 |
| Accuracy class | 1.6 |
| Case | Stainless steel 304 (1.4301), bayonet ring case |
| Wetted parts | Stainless steel 316L (1.4404) |
| Process connection | 6 mm external tube diameter / clamping-ring fitting |
| Electrical accessory | Indirect Reed contact, type R |
| Reed contact configuration | R4 |
| Degree of protection | IP54 |
| Dial | White aluminium dial with black scale |
| Pointer | Black aluminium pointer |
| Window | Laminated safety glass |
| Connection configuration | Lower connection, suitable for RSCh 63-3 |
| Country of manufacture | Germany |
References
Part Numbers
Xylem Article No.
47151
Xylem Prefix
7600000047151
ARMANO model
RSCh 63-3
Reed Contact R4
- Electrical accessory: indirect Reed contact, type R
- Switching function / configuration: R4
- Degree of protection: IP54
Please confirm the required switching function for your system when ordering.
Applications
- Mechanical pressure measurement in industrial systems
- Pressure measurement combined with switching via Reed contact
- Installations using 6 mm clamping-ring / Swagelok-type tube fittings
- Replacement of existing RSCh 63-3 gauges (Xylem Article No. 47151)
Manufacturer
ARMANO Messtechnik GmbH, Germany. Supplied in Australia and worldwide by Ozone UV Solutions Pty Ltd.
Request Technical Documentation
Need product data for this gauge? Request it with your quote and our team will send it to you.
