Portable Ozone Gas Detector – 0–1 ppm O3, Integrated Sampling Pump, IP65
A compact, hand-held ozone gas detector for portable ozone safety checks. An integrated sampling pump draws air to an electrochemical O3 sensor, and audible, visual LED and vibration alarms warn the user when ozone reaches the set levels — all in a rugged IP65 enclosure powered by a rechargeable battery.
- Measures 0–1 ppm O3
- Integrated sampling pump
- Low / high alarms 0.08 / 0.1 ppm, adjustable
- Up to 1,200 alarm records, PC connection
Price
Enquire About Price
Priced on application · freight quoted with order
Talk to an engineer
Not sure this ozone detector suits your site? Tell us how you plan to use it and our team will help.
+61 422 081 913At a glance
Key Features
Integrated Sampling Pump
Active sampling for spot checks and confined locations.
Electrochemical Ozone Sensor
Designed for ozone concentration measurement.
Multi-Mode Alarm
Audible, visual LED and vibration indicators.
Data Logging
Stores up to 1,200 alarm records.
PC Connectivity
Supports connection to a PC.
Rugged IP65 Enclosure
Durable enclosure with IP65 ingress protection.
Colour LCD
2.4-inch colour display.
Rechargeable Battery
3.7 VDC, 3600 mAh rechargeable lithium battery.
Product description
Portable Ozone Gas Detector
This portable ozone detector gives technicians and maintenance teams a quick way to check ozone levels on the spot. Instead of relying on a fixed monitor in one position, the user can carry the instrument to the area being checked and read the O3 concentration directly on its 2.4 inch colour LCD.
Because the sample is drawn in by a built-in pump rather than relying on air moving past the sensor, the detector is well suited to spot checks and to confined locations where air movement is limited. The IP65 enclosure protects the instrument during day-to-day handling, and the rechargeable lithium battery runs for approximately 10 hours under non-alarm conditions.
For fixed, continuous ambient ozone monitoring in a plant room, see our Honeywell Satellite XT ozone monitor. For ozone off-gas treatment, see our ozone destruct catalyst media.
Technical data
Technical Specifications
| Measurement range | 0–1 ppm O3 |
|---|---|
| Low alarm | 0.08 ppm |
| High alarm | 0.1 ppm |
| Alarm thresholds | Adjustable |
| Sampling method | Integrated sampling pump |
| Sensor technology | Electrochemical |
| Display | 2.4 inch colour LCD |
| Operating temperature | -20°C to 60°C |
| Humidity | 5–95% RH, non-condensing |
| Power | 3.7 VDC, 3600 mAh rechargeable lithium battery |
| Operating time | Approximately 10 hours under non-alarm conditions |
| Charge time | 4–6 hours |
| Sound | 85 dB at 1 m |
| Dimensions | 174 × 68 × 47 mm |
| Weight | 210 g |
| Ingress protection | IP65 |
| Data logging | Up to 1,200 alarm records |
| PC connectivity | Supported |
| Gas concentration curve | Supported |
| Warranty | 1 year |
Ozone Detection and Sampling
The detector measures ozone (O3) over a range of 0–1 ppm using electrochemical sensor technology. Its integrated sampling pump actively draws air to the sensor, so readings can be taken at the point being checked.
Alarm Functions
- Audible alarm — 85 dB at 1 m
- Visual LED indication
- Vibration indication
- Low alarm: 0.08 ppm
- High alarm: 0.1 ppm
- Adjustable alarm thresholds
Data Logging and PC Connectivity
- Stores up to 1,200 alarm records
- Connects to a PC
- Gas concentration curve display
- Adjustable alarm thresholds
Applications
- Portable ozone safety checks
- Ozone concentration spot checks
- Checking ozone in confined locations
- Industrial ozone monitoring
- Maintenance and service inspections
- Checking areas where ozone may be present
Product Information
- Product: Portable Ozone Gas Detector
- Gas: Ozone (O3)
- Warranty: 1 year
- Supplied by Ozone UV Solutions Pty Ltd, with worldwide shipping
Request Technical Documentation
Need technical documentation for this ozone gas detector? Contact our team and request the relevant product documentation.
Frequently Asked Questions
What is a portable ozone gas detector?
A portable ozone gas detector is a hand-held instrument that measures the concentration of ozone (O3) in the surrounding air and alarms when preset levels are reached. This detector is designed for portable ozone safety checks, using an integrated sampling pump and an electrochemical sensor.
What is the measurement range of this ozone detector?
The detector measures ozone in the range 0–1 ppm O3.
Does the ozone detector have an integrated sampling pump?
Yes. The integrated sampling pump actively draws a sample to the sensor, which suits spot checks and confined locations.
What type of sensor does the ozone detector use?
It uses an electrochemical ozone sensor.
What are the alarm levels?
The low alarm is set at 0.08 ppm and the high alarm at 0.1 ppm. The alarm thresholds are adjustable. Alarms are indicated by an audible alarm (85 dB at 1 m), visual LED indication and vibration.
How long does the battery last?
The 3.7 VDC, 3600 mAh rechargeable lithium battery provides approximately 10 hours of operation under non-alarm conditions. Charge time is 4–6 hours.
Does the detector record alarm events?
Yes. The detector logs alarm events, supports PC connectivity and can display a gas concentration curve.
How many alarm records can it store?
Up to 1,200 alarm records.
Is the ozone detector IP65 rated?
Yes. The enclosure has IP65 ingress protection.
What is the operating temperature range?
-20°C to 60°C, at 5–95% RH non-condensing humidity.
What are the dimensions and weight of the detector?
The detector measures 174 × 68 × 47 mm and weighs 210 g.
