ULTRAAQUA · LOW-FLOW UV DISINFECTION FOR CORROSIVE WATER
LOW FLOWRATE PP Series
Compact UV systems with one to four lamps and non-corrosive polypropylene reactors, for low flows of saline and corrosive water.
Pricing on request.
Overview
The LOW FLOWRATE PP series brings the non-corrosive polypropylene reactor to small systems. With one to four 75 W lamps and reactors weighing between 3 and 8 kg, it suits low-flow lines in aquaculture, aquariums and process water where a stainless-steel reactor would corrode. Designed for low flows, typically 1–30 m³/h; final sizing confirmed on request.
Ozone UV Solutions supplies LOW FLOWRATE PP systems as an authorised ULTRAAQUA reseller and supports them locally: from sizing and installation through commissioning, servicing, lamps and spare parts.
Key features
- UV-stabilised polypropylene reactor for saline and corrosive water [PEHD]
- One to four ULTRATHERM 75 W low-pressure high-output amalgam lamps with a rated life of 9,000 hours
- Compact reactors from 3 to 8 kg with 1½" or 3" BSP connections, design pressure 6 bar
- Two controller levels: STD with status LEDs and hour counter, or ADV with UV intensity sensor and LCD
- 50–100% variable lamp power and Modbus RTU on ADV units
- Optional automatic ULTRAWIPERâ„¢ quartz sleeve cleaning (not available on MR1-75PP STD)
Typical applications
- Recirculating aquaculture systems (RAS), shrimp and prawn farming
- Aquariums and zoo life-support systems
- Horticulture, and food and beverage applications
Models and specifications
Models (75 W lamps) – each available as STD or ADV
| Model | UV lamps (75 W) | Connection | Power | Reactor dry weight | Reactor volume | Vent / drain ports | Control cabinet STD (H×W×D mm · weight) | Control cabinet ADV (H×W×D mm · weight) |
|---|---|---|---|---|---|---|---|---|
| MR1-75PP | 1 | 1½" BSP | 0.08 kW | 3 kg | 5 L | None | 300×200×150 · 6 kg | 600×400×210 · 10 kg |
| MR2-75PP | 2 | 3" BSP | 0.16 kW | 5 kg | 13 L | ½" | 400×300×210 · 10 kg | 600×400×210 · 10 kg |
| MR3-75PP | 3 | 3" BSP | 0.24 kW | 6 kg | 15 L | ½" | 600×400×210 · 14 kg | 600×400×210 · 12 kg |
| MR4-75PP | 4 | 3" BSP | 0.32 kW | 8 kg | 17 L | ½" | 600×400×210 · 16 kg | 600×400×210 · 12 kg |
STD and ADV controllers compared
| Feature | STD | ADV |
|---|---|---|
| UV intensity monitoring | – | Non-corrosive PTFE sensor, UV intensity on display, pre-alarm and alarm |
| Lamp power | Fixed | Variable 50–100% |
| Control logic / display | Status LED indicators and hour counter | Microprocessor with 4-line LCD and system state indication |
| Communication | – | Modbus RTU |
| Analogue I/O (4–20 mA) | – | Flow input, UV irradiance output |
| External wiring | – | Remote ON/OFF, safety ON/OFF, system status, alarm |
| Logging | – | Alarms |
Common specifications
| UV LAMPS & MONITORING | |
|---|---|
| Lamp type | ULTRATHERM low-pressure high-output (LPHO) amalgam, 75 W |
| Rated lamp life | 9,000 hours |
| UV monitoring | ADV: UV intensity sensor, non-corrosive PTFE |
| Approvals | CE [UL / cUL] |
| UV CHAMBER | |
| Chamber material | Non-corrosive UV-stabilised polypropylene (PP) [PEHD], machined finish |
| Connections | 1½" BSP (MR1-75PP) · 3" BSP (MR2 to MR4-75PP) · pressure class PN10 (ANSI Class 150) |
| Design pressure | 6 bar (higher ratings on request) |
| Quartz sleeves | High-purity fused quartz, transmittance > 92% |
| Cleaning | [ULTRAWIPER™ automatic mechanical wiper with PTFE/steel fibre rings (electric drive)] – not available on MR1-75PP STD |
| Access / installation | Single-ended service · horizontal or vertical installation · free-standing [horizontal SS316 stand] · IP65 / NEMA 4X |
| Temperature probe | PTC sensor |
| CONTROL CABINET | |
| Cabinet | Polycarbonate [SS304 / SS316] · wall-mounted, ambient 0–40 °C · IP65 · passive cooling [fan / AC / heat exchanger] |
| Power supply | 1 × 200–240 VAC ±10% +N+PE 50/60 Hz |
| Cable length | 4 m standard [up to 30 m] |
Pricing on request.
